TECHNICAL CHARACTERISTICS:
Supply voltage and frequency: 380 – 400V; 50 – 60Hz
Self-check mode
Control history
Easy to use interface
Change access parameters
Automatic download of the tester
Automatic reconfiguration of control parameters
Number of measuring positions: 16 (8 left and 8 right)
Automatic system for adjustment and adaptation to temperature and humidity
Tightness control of boxes with (rectangular and round) filling form
The maximum dimensions of rectangular boxes are: 50 (a) * 90 (b) * 100 (h) to 230 * 230 * 365
The maximum size of round boxes is: 90 (D) * 100 (h) to 230 * 365
The standard diameters of the filling holes are: 22 mm, 32 mm, 42 mm, 57 mm, 85 mm, 125 mm
Control of pressure drop rate in controlled box
Air pressure inside the can during testing: 0,1 bar to 0,4 bar
